Refrigerator Water Filter Compatible GXRTDR, GXRTQR

Refrigerator Water Filter Compatible Codes

Refrigerator	Water Filter Models
LG	5231JA2010A； 5231JA2010B； 5231JA2010C
Samsung	DA29-10105J
GE	GXRTDR； GXRTQR
Aqua Fresh	WF283
Liebherr	SBS7052-4
Omnipure	R200； K2567JJ;  K5567BB
Water Sentinel	WSI-1
Pentek	GS-10-B； GS-10-JG14； GS-215-CB5-B； GS-6RO-B
Culligan	IC-100-D
Aqua-Pure	APIL3R

Basic Parameters of Refrigerator Water Filte

Model NO	RWF0300A
Unit/Case	40 Units
Case Weight	34.8pounds
Case Dimension	21.3“ x 13.8“ x 13“
Cases/Pallet	24Cases   (Based on 39.4”x39.4”, or 43.3”x43.3” pallet)
Pallet Weight	862.4pounds
Pallet Dimension	42.5”x 42.5”x  55.5”
Individual Filter Dimension	OD: 1.5"    Length: 9.4"
Individual Unit Weight With Box	13.9oz
Individual Unit Box  Dimension	2.4" x 2.4" x 11.3"
OPERATING TEMP	34-100℉
OPERATING PRESSURE	30-120psi
FLOW RATE	0.5-1 GPM
FILTRATION LIFE:	6 months/1500G(Depends on water quality and level of contaminants

Installation  instruction
 1.Shut off the main water supply valve to the refrigerator.
 2.Apply the month sticker to the new cartridge and mark your calendar to remind you to replace the filter after six months.
 3.Cut tubing using a tubing cutter for copper, use a sharp knife for plastic tubing.  Cut tubing square, not on an angle (angle cuts can cause leaks)
 4.Smooth any burrs on copper tubing with steel wool or file
 5.Pop up end cap on filter, insert tubing
 6.Lock tubing in place by pressing end cap down
 7.Hold the filter over a bucket
 8.turn on water supply.  Flush the filter for 3-4 gallons (approximately 6-8 minutes)
 9.Turn off water supply.  Repeat process for the other end of the filter
 10.Turn water back on and check for leaks.
